5 Ton Mechanical Trolley Jack CRS Plate Adjustable Saddle

Name: 5 Ton Mechanical Trolley Jack CRS Plate Adjustable Saddle
Brand: Hangzhou JENTAN Machinery Co., Ltd.
SKU: JTMJ-B
Price: 542.80 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Jentan

Certification: CE;GS;EN;ISI;AU;UL;CUL;TUV

Model Number: JTMJ-B

Payment & Shipping Terms

Minimum Order Quantity: 1 piece

Price: Negotiation

Delivery Time: 7-60 days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 500000pcs per year

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              5Ton mechanical trolley jack, Adjustable mechanical trolley jack, Adjustable 5 ton mechanical jack


Features:	Adjustable Saddle, Swivel Casters, Overload Protection	Dimensions:	24 X 12 X 12 Inches
Warranty:	1 Year	Color:	Yellow
Application:	Lifting Heavy Equipment And Machinery	Material:	Steel
Load Capacity:	5000 Lbs	Type:	Hydraulic
Manufacturer:	XYZ Corporation	Weight:	100 Lbs
Lifting Height:	48 Inches	Usage:	Industrial

Features:	Adjustable Saddle, Swivel Casters, Overload Protection
Dimensions:	24 X 12 X 12 Inches
Warranty:	1 Year
Color:	Yellow
Application:	Lifting Heavy Equipment And Machinery
Material:	Steel
Load Capacity:	5000 Lbs
Type:	Hydraulic
Manufacturer:	XYZ Corporation
Weight:	100 Lbs
Lifting Height:	48 Inches
Usage:	Industrial

Description

5 Ton Mechanical Trolley Jack CRS Plate Adjustable Saddle

JTMJ-B Model Mechanical Jack

* Double pawl brake system-quick braking,safe and reliable.
* Low gearing tolerance-smooth transmissions,free of jerks.
* High efficiency and minimun turning force less than 25kgs is required to lift full load of all rated capacity.
* Sturdy structure,light weight and quick lift peformance material high quality CRS plate,carburized alloy steel gears.
* The Ableforge steel hack si designed and developed for heavy industrial lifting applications,strictly in accordance with the latest safety standard DIN 7355.

5 Ton Mechanical Trolley Jack CRS Plate Adjustable Saddle 0

规格 Model			1.5t	3t	5t	10t
额定载重量Rated capacity		t	1.5	3	5	10
试验载荷 Test load		KN	18.4	36.8	61.3	122.5
满载时的手摇力 Chain shake to lift full load		N	150	280	280	560
行程 Stroke		mm	300	350	350	410
最低起升高度 Min.lifting height	mm	F	25	40	40	40
最低起升高度 Min.lifting height	mm	H	600	735	735	805
主要尺寸 mm Dimensions	A		163	197	189	250
	B		206	219	258	318
	C		289	316	355	523
	D		160	170	200	220
	E		55	60	70	86
	G		140	150	170	170
	K		113	127	127	248
	R		225	250	275	300
净重 Net weight		kg	14.8	23.3	31.3	49
